PRODUCT FEATURES
Compliant with ROSH & CE certification;
The wet parts complies food grade requirements;
The pressure-containing member adopts high strength plastic and metal materials;
The materials of sealing parts are all imported;
Equipped with high power DC motor with low noise,low vibration;
Totally inspection control in production process for electrical, sealing and water;
Nano filtration diaphragm pump is both storing pressure and self suction function.
PRODUCT PARAMETERS
| Model | LFP1150N | LFP1200N | LFP1300N |
| Voltage | 24VDC | 24VDC | 24VDC |
| Connection Thread | 3/8"NPT (general) | 3/8"NPT (general) | 3/8"NPT (general) |
| Inlet water pressure | 0MPa | 0MPa | 0MPa |
| Operating pressure | 0.35MPa | 0.35MPa | 0.35MPa |
| Current | ≤1.2A | ≤1.5A | ≤2.0A |
| Work flow | ≥1450mL/min | ≥1700mL/min | ≥2600mL/min |
| Open flow | ≥1650mL/min | ≥2000mL/min | ≥3000mL/min |
| Max Pressure | 0.5-0.55MPa | 0.5-0.55MPa | 0.5-0.55MPa |
| Max Current | 1.5A | 2.0A | 2.5A |
