Compliant with ROSH & CE certification
The wet parts complies food grade requirements
The pressure-containing member adopts high strength plastic and metal materials.
The materials of sealing parts are all imported.
Equipped with high power DC motor with low noise, low vibration.
Totally inspection control in production process for electrical, sealing and water System
PRODUCT PARAMETERS
| Model | LFP1050 | LFP1075 | LFP1100 |
| Voltage | 24VDC | 24VDC | 24VDC |
| Connection Thread | 3/8"NPT (general) | 3/8"NPT (general) | 3/8"NPT (general) |
| Inlet water pressure | 0.2MPa | 0.2MPa | 0.2MPa |
| Operating pressure | 0.5MPa | 0.5MPa | 0.5MPa |
| Current | 0.7A | 0.9A | 1.2A |
| Work flow | 550mL/min | 750mL/min | 980mL/min |
| Open flow | 1600mL/min | 1800mL/min | 2000mL/min |
| Max Pressure | 0.85-1.0MPa | 0.85-1.0MPa | 0.85-1.0MPa |
| Max Current | 1.0A | 1.2A | 1.4A |
| Pure water/ condensed water | 1:3 | 1:3 | 1:3 |
