PRODUCT FEATURES
Compliant with ROSH & CE certification;
The wet parts complies food grade requirements;
The pressure-containing member adopts high strength plastic and metal materials;
The materials of sealing parts are all imported;
Equipped with high power DC motor with low noise, low vibration;
Totally inspection control in production process for electrical, sealing and water
Nano filtration diaphragm pump is both storing pressure and self suction function.
PRODUCT PARAMETERS
| Model | LFP1050N | LFP1075N | LFP1100N |
| Voltage | 24VDC | 24VDC | 24VDC |
| Connection Thread | 3/8"NPT (general) | 3/8"NPT (general) | 3/8"NPT (general) |
| Inlet water pressure | 0MPa | 0MPa | 0MPa |
| Operating pressure | 0.35MPa | 0.35MPa | 0.35MPa |
| Current | ≤0.7A | ≤0.7A | ≤0.7A |
| Work flow | ≥550mL/min | ≥750mL/min | ≥980mL/min |
| Open flow | ≥1000mL/min | ≥1150mL/min | ≥1300mL/min |
| Max Pressure | 0.5-0.55MPa | 0.5-0.55MPa | 0.5-0.55MPa |
| Max Current | 0.96A | 1.0A | 1.25A |
