LFM208 Residual Pressure Transducer, 0~±100Pa

The residual pressure transducer is a device used to detect the air pressure of the fire exit. Usually, the air pressure of the fire exit needs to be higher than other rooms and areas to prevent the smoke and harmful gas from overflowing into the fire exit. When the pressure value of the device is lower than the normal value, it means that there is a safety hazard risk in this fire passage.



Features

CQC certificated

For fire fighting system Application

Pressure monitoring for fire exits. And prevent the leakage of toxic gases and dense smoke when fire broke out.



Description

Adopt American imported pressure sensing element

Elevator front room and staircase of high-rise building

Basement and refuge

Pressure monitoring in hotels, shopping malls, hospitals and

other public places

Compliant with The National Standard

?Technical Standard for Smoke Management System in Buildings?



Specification

Measurement	range 0~±100Pa
Accuracy (a)	±1%F.S
Working temperature	-20°C~75°C
Compensated temperature	-5°C~60°C
Protection Grade	IP30
Power Supply	24VDC±2.4V
Consumption	≤0.75W
Trachea connection	+ High voltage side  - Low pressure side; adopt 3.5mm inner diameter hose
Instructions	Green status, red alarm indicator
Display method	With display/without display
Measured medium	Air and non-corrosive gas
Control signal(b)	switching value
Communication mode	Two bus (two-wire system)/RS-485 (four-wire system)
Withstand voltage	1000Pa
