LF08H Cooling Fan Pressure Switch, 0.2~45bar

This product is generally used for cooling fans, long life can be applied to the frequent start of fan fans. This product can also meet the demand for pressure control equipment with relatively long service life requirements.

Specification

Model LF08H
Media Air,Water,motor,lils,transmission oils,Hydrocarbon Media,Refrigeration fluid
Pressure Range/
Tolerance/
Proof Pressure
Pressure Range Tolerance Proof Pressure
0.2~6bar(low presure) ±0.5bar 15bar
6~10bar ±0.7bar 35bar
11~20bar ±1bar 45bar
21~30bar ±1.5bar
31~45bar ±1.5bar
Burst Pressure 5000psi
Operating Temperature Range Environment temperature:low pressure:-30~65??High pressure:-35~120?
Medium temperature:-50~120?
Switch Type SPST(NC OR NO);SPDT
Electric Rating 250VAC,0.02~10A
Endurance 300000
More information about product
  • svg LF08H
