Specification
| Specification | 1...150cm/s(Water),3...300cm/s(Oil),20...2000cm/s(Gas) |
| Setting Range | PNP,NPN,Relay Type,NO+NC |
| Signal output | 24V±20%DC |
| Power Supply | Max 400mA(PNP,NPN);Max 1A@24V ac/dc (Relay Type) |
| Turn on current | Max 80mA |
| No-load current | LED (6pcs) |
| Flow indication | Potentiometer Setting |
| Setting Type | 100bar |
| Proof Pressure Range | ≤4?/s |
| Medium temperature change | 1--13s,Typical value 2s |
| Initializtion time | About 8s |
| Electrical protection | Reverse, short circuit, overload protection |
| Protection level | IP67 |
| Medium temperature | -20~80°C |
| Ambient temperature | -20~80°C |
| Storage temperature | 20~80°C |
| Connection mode | M12 Socket Connector |
| Material | Probe: stainless steel?Housing: stainless steel |
| Weight | About 0.4kg |
