Specification
Specification | 1...150cm/s(Water),3...300cm/s(Oil),20...2000cm/s(Gas) |
Setting Range | PNP,NPN,Relay Type,NO+NC |
Signal output | 24V±20%DC or 230V±15%DC |
Power Supply | Max 400mA(PNP,NPN);Max 1A@24V ac/dc (Relay Type) |
Turn on current | Max 80mA |
No-load current | LED (6pcs) |
Flow indication | Potentiometer Setting |
Setting Type | 100bar |
Proof Pressure Range | ≤4?/s |
Medium temperature change | 1--13s,Typical value 2s |
Initializtion time | About 8s |
Electrical protection | Reverse, short circuit, overload protection |
Protection level | IP67 |
Medium temperature | -20~80°C |
Ambient temperature | -20~80°C |
Storage temperature | 20~100°C |
Connection mode | M12 Socket Connector |
Material | Probe: stainless steel?Housing: PBT |
Weight | About 0.4kg |
